PRODUCT
FRP Cable Tray — Durable, Corrosion-Proof Cable Management
High-strength fiberglass cable trays for industrial, chemical, and offshore applications. Channel, ladder, and perforated types available.
Gallery
FRP Ladder Type Cable Tray
FRP Perforated Cable Tray
FRP Cable Tray Installation
FRP Cable Tray System Overview
Overview
What Is an FRP Cable Tray?
An FRP (Fiberglass Reinforced Plastic) cable tray is a lightweight yet extremely strong cable support system designed for industrial cable management. Manufactured through the pultrusion process using fiberglass rovings and thermosetting resins, FRP cable trays provide superior corrosion resistance, electrical insulation, and structural integrity in the most demanding environments.
Unlike traditional steel or aluminum cable trays, FRP variants do not rust, corrode, or conduct electricity. This makes them the preferred choice for chemical plants, offshore platforms, wastewater treatment facilities, and power generation stations where exposure to corrosive agents, moisture, and electrical hazards is a daily concern.
Available in channel, ladder, and perforated configurations, FRP cable trays can be customized to suit any cable routing layout. With a high strength-to-weight ratio, UV-resistant options, and self-extinguishing fire-retardant properties, they deliver reliable performance for decades with minimal maintenance.
High-quality pultruded FRP profile
Specifications
Specifications
Technical Specifications
Dimensiones
Available in standard lengths and custom sizes.
| Parameter | Value |
|---|---|
| Material | Fiberglass Reinforced Plastic (FRP) – Isophthalic Polyester / Vinyl Ester |
| Standard Width | 150 mm, 300 mm, 450 mm, 600 mm, 900 mm |
| Standard Length | 3,000 mm (custom lengths up to 6,000 mm available) |
| Load Rating | 75 – 200 kg/m depending on width and depth configuration |
| Fire Resistance | Class 1 Flame Spread (BS 476 Part 7) / Self-extinguishing |
| Operating Temperature | -40°C to +120°C (continuous) |
| Corrosion Resistance | Excellent – Resistant to acids, alkalis, salts, and UV exposure |
| Color Options | Gray, Yellow, Orange, Green, or Custom RAL |
Features
Features & Benefits
Features
Superior Corrosion Resistance
FRP cable trays withstand harsh chemicals, saltwater, and acidic environments. Unlike steel, they never rust or corrode, providing decades of maintenance-free service in chemical plants, offshore platforms, and wastewater treatment facilities.
Electrically Non-Conductive & Spark-Proof
FRP is electrically insulating and non-sparking, making it ideal for cable management in power substations, data centers, and hazardous environments where electrical safety is critical.
Lightweight with High Strength-to-Weight Ratio
Weighing approximately one-fourth the weight of steel, FRP cable trays are easy to transport, handle, and install. Despite their light weight, they offer structural strength comparable to steel under normal load conditions.
Fire-Retardant & Self-Extinguishing
FRP cable trays are manufactured with fire-retardant resin systems that meet Class 1 flame spread ratings (BS 476). They self-extinguish when the flame source is removed, enhancing overall plant safety.
UV-Resistant & Weatherproof
With UV-stabilized resin formulations, FRP cable trays resist degradation from sunlight and extreme weather. Suitable for both indoor and outdoor installations across all climate zones.
Multiple Configurations
Available in channel type, ladder type, and perforated type to suit different cable loading requirements. All configurations come with compatible fittings, brackets, and covers for a complete cable management system.
Applications
Applications
Chemical Processing Plants
Corrosion-resistant cable management for aggressive chemical environments
Offshore Oil & Gas Platforms
Saltwater-resistant cable support for offshore and marine installations
Power Generation Facilities
Non-conductive cable routing for substations and power plants
Wastewater Treatment Plants
Moisture and chemical resistant cable support for treatment facilities
